    2026 Kioti NX5010H

    NX5010H Compact Utility Tractor

    The KIOTI NX5010H is a 50-horsepower compact utility tractor with a hydrostatic transmission, an independent PTO, and a lift capacity of over 3,000 lbs., and more. variety of tasks.

    Features May Include:

    Eco-Friendly Diesel Engine

    • The whisper-quiet, eco-friendly KIOTI Tier 4 CRDI engine improves fuel efficiency while reducing noise levels. Silence and strength go hand-in-hand, letting you conquer every task with quiet confidence.

    PTO Cruise

    • Engage it with a tap, and your engine locks into a steady RPM, guaranteeing precise and efficient implement operation. Simply click the switch to adjust PTO speed on the fly—all without ever shifting gears or wrestling with the throttle.

    Projection and Working Lamp

    • With the new projection head and working lamp, the operator will experience safer and easier operation after the sun goes down.

    Torque Compensation

    • This feature acts like a master engineer, automatically adjusting the engine torque level to maintain a steady, unwavering flow of power.

    Hydrostatic Power Steering

    • Hydrostatic power steering makes even the tightest, most repetitive turns a breeze. And for peak comfort, you can tilt the steering wheel to your perfect position with a simple push of a lever.

    Anti-Stall Function (HST Models)

    • Automatically engages to prevent sudden engine stalls caused by momentary overload, helping you maintain consistent power and momentum. For added control during delicate tasks, a maximum speed limit can be set to ensure smooth, precise operation.

    Info

    Industry

    Agriculture

    Make

    Kioti

    Model

    NX5010H

    Trim

    Base

    Year

    2026

    MSRP

    N/A

    Category

    Tractor

    Subcategory

    Compact


    Specs

    Engine

    Model: 3F183T | Engine Manufacturer: KIOTI | Aspiration: Turbo Charged

    Power/Horsepower

    50 hp (37.30 kW)

    Displacement

    111.40 cu. in. (1,826 cc)

    RPM

    2,600 rpm

    Fuel Type

    Diesel

    Fuel Capacity

    14.80 gal (56 L)

    Transmission

    Hydrostatic | Shuttle: Synchronized | Travel Speeds Forward: 16 | Travel Speeds Reverse: 16 | Travel Speeds Minimum Speed: 0 mph (0 km/h) | Travel Speeds Maximum Speed: 16.52 mph (26.59 km/h) | Travel Speeds Min Reverse Speed: 0 mph (0 km/h) | Travel Speeds Max Reverse Speed: 16.52 mph (26.59 km/h)

    PTO Type

    Independent | PTO Power: 38.90 hp (29 kW) | Rear Speed: 540 rpm | Mid Speed: 2,000 rpm (Optional)

    Brakes

    Wet Multi Disc

    Clutch

    None

    Steering

    Hydrostatic Power Steering

    Notes

    Hydraulics - Pump: Gear | Hydraulics - Pump Capacity: 17.90 gpm (67.60 lpm) | Hitch - Type: Three Point | Hitch - Category: Category 1 | Hitch - Control Type: Position with Draft Control

    Load Capacity

    Hydraulics - Lift Capacity: 3,177 lb (1,441 kg) | Hitch - Lift Capacity: 3,177 lb (1,441 kg)

    Length

    With Hitch: 139.60 in (3,547 mm)

    Width

    65.60 in (1,665 mm) | Front Tread: 55.20 in (1,352 mm) | Rear Tread: 52.10 in (1,324 mm)

    Wheelbase

    75.60 in (1,920 mm)

    Ground Clearance

    13.70 in (350 mm)

    Turning Radius

    9.81 ft (2.99 m)

    Weight

    4,000 lb (1,814.40 kg)

    Height

    103.10 in (2,618 mm)

    Tires

    Agricultural - Front: 8-16 | Agricultural - Rear: 13.6-24 | Industrial - Front: 10-16.5 | Industrial - Rear: 14.9-24 | R14 - Front: 10-16.5 | R14 - Rear: 17.5 - 24 | Turf - Front: 29-12.5-15 | Turf - Rear: 21.5L-16.1

    Warranty

    Non-Commercial Application: 24 Months, Coverage: Parts & Labor | Rental and Commercial Application: The first to occur of 24 months of 1500 hours, Coverage: Parts & Labor
