2024 Beaver Valley Supply Co WOGLBH-2072R

Worksaver Rotating B

Worksaver Rotating Bale Handlers

• Designed for tractor front loaders that use the Euro/Global quick attach system
• Unit will gently handle wrapped and unwrapped round bales from 4-ft to 6-ft in diameter
• Rated at 2,200 lbs.
• Unit includes hydraulic cylinder less hoses

The “R” series is leading the way in stacking bales. The “R” series allows the operator to pick up a bale rotate it up to 110⁰ and stack it like a soup can for increased versatility. All without having to place the bale down and re-position the clamps. This eliminates double handling, saving the operator time when unloading from a trailer. Optional solenoid kit for power units equipped with single auxiliary valve includes hoses & couplers.

Power Unit / Loader Requirements

The standard Bale Hand will require a tractor of at least 40-50 hp in size.The rotating Bale Hand (“R” Series) will require a tractor of 60-80 hp in size. The loader or skid steer unit also needs to have sufficient lift capacity to handle the bale and the weight of the Bale Hand. Both the standard Bale Hand and the “R” Series, will gently handle large round wrapped/unwrapped bales up to 2,200 lbs. It features smooth curved clamping arms to prevent puncturing wrapped bales, yet securely clamping them during transport.

Power unit needs to be equipped with two auxiliary valves or a solenoid kit is required. The power unit needs to have sufficient lifting capacity to handle the bale, make sure the power unit is properly counter-balanced with weight prior to moving bales.

ale Handler | Euro Global | Rated 2,200 lbs. | 60-80 HP
